U.S. Motors - ASB796 C-Flange 1.5HP Full Rated 56J 115/230V Pool & Spa Pump Motor

U.S Motors  ASB796 C-Flange 1.5HP Full Rated 56J 115/230V Pool  Spa Pump Motor
U.S Motors  ASB796 C-Flange 1.5HP Full Rated 56J 115/230V Pool  Spa Pump Motor
ASB796 C-Flange 1.5HP Full Rated 56J 115/230V Pool & Spa Pump Motor

U.S. Motors - ASB796 C-Flange 1.5HP Full Rated 56J 115/230V Pool & Spa Pump Motor

Item No. 38566
Manufacturer SKU: ASB796
4.9 out of 5 Customer Rating
The U.S. Motors Emerson ASB796 C-Face 1.5HP Full Rated 56J 115V/230V Single Speed Pool and Spa Pump Motor is a powerfully designed replacement motor. More Details

subscription order icon Membership Available

$439.99

Earn at least $21 in pool perks for this item by joining Pool Perks.

You can buy this product once, or subscribe to have this product delivered to you as frequently as you wish.

You can edit or cancel your membership anytime.
How to get it
Delivering to 20151 Update Cancel
Please note: This item is only available for in-store pickup and the selected store is out of stock. Please select a nearby store with available inventory to process your order.
Store Pickup Pickup In Store
Standard Shipping - Ship To Home
Pick up on Tuesday, Apr 04
- Pickup at Chantilly, VA 13932 Lee Jackson Memorial Hwy Ste
Want it today?
Check nearby in-stock stores

Description

The U.S. Motors Emerson ASB796 C-Face 1.5HP Full Rated 56J 115V/230V Single Speed Pool and Spa Pump Motor is a powerfully designed replacement motor.
  • Shaft Threads - 7/16-20 UNF-2A
  • 50 Degree C Ambient
  • Triple Bearing Protection
  • 1081 Design
  • Continuous Duty
  • Class B Insulated
  • Sealed Ball Bearings
  • Thermally Protected
  • Service Factor: 1.3
  • RPM: 3450
  • Length without Shaft: 12.02
  • 8.7-7.8/15.6A 208-230/115V

Details

The U.S. Motors Emerson ASB796 C-Face 1-1/2 HP Full Rated 56J 115V/230V Pool and Spa Pump Motor is a powerfully designed replacement motor.

Similar to spa and pool replacement motors, the Emerson 56 C-Flange Motor is a two-compartment model with a voltage selection device, running at 1.5HP and 115V/230V. It is Class B-insulated for efficient operation and has been designed with both sealed ball bearing sand triple bearing protection. The Emerson replacement motor has an open drip proof design for water damage prevention and is thermally protected.

Please Note: When replacing the motor on the pump, replacing the mechanical pump seal is required to ensure proper installation. Pump seal size varies depending on the pump and not the motor.

Highlights

Single Phase
Featuring basic Single Phase wiring, the Emerson 56 C-Flange Motor delivers efficient operation. Little maintenance is required and the Emerson 56 C-Flange Motor is built to last
J-Frame
The Emerson 56 C-Flange Motor features a J-Frame that's ideal for jet pump service and is completely versatile with its threaded shaft and 56 C-Flange face
Energy Efficiency
The Emerson 56 C-Flange Motor operates at a higher efficiency level than standard motors. It has longer insulation and bearing lives, with lower heat output and vibration. With aggressive performance and lower failure rates, energy expenditures are greatly diminished, saving heavily on operating costs

Specs

Flange Type: J Flange
Speed Settings: Single Speed
Energy Efficiency: High Energy Efficiency
Service Factor: 1.25 - 1.50
Voltage: 115V / 208 - 230V
Voltage: 120V / 240V
Pool Type: In Ground
Horsepower: 1-1/2 HP
Rating Type: Full-Rated
Product Type: Pool Motor
Motor Frame: 56 Frame
Manufacturer: U.S. Motors Emerson


Warranty

See Owner's Manual for details
