U.S. Motors - Emerson 48 Y-Frame Thru-Bolt Single Speed 2-1/2HP Full-Rated Pool and Spa Motor, 10A 230V
$399.99
The Emerson 48 Y-Frame Thru-Bolt motor is a powerfully designed motor for your pool or spa.
More Details
How to get it
Store Pickup
Pickup In Store
The Emerson 48 Y-Frame Thru-Bolt motor is a powerfully designed motor for your pool or spa.
- Class F Insulated
- 1081, 1563 and 1795 Design
- 50 Degrees Celsius Ambient
- 3 Oft.Clock Conduit
- Shaft Thread 3/8-16 UNC 2A RH
- 3 1/2". Shaft Height
- Service Factor: 1.3
- RPM: 3450
- Amps: 10
The Emerson 48 Y-Frame Thru-Bolt motor is a powerfully designed motor for your pool or spa. Its capacitor start design runs on high efficiency and performs continuously. Its rigid base and thermal protection provides additional support giving you long lasting performance. The Emerson 48 Y-Frame Thru-Bolt motor features a smaller 48 frame size and has an open drip proof enclosure that keeps water from flowing into the motor. It also has a rear mounted fan that keeps the motor cool during operation. The Emerson 48 Y-Frame Thru-Bolt is a single speed pool and spa motor with full-rated 2 1/2"HP for reliable power.
Featuring basic Single Phase wiring, the Emerson 48 Y-Frame Thru-Bolt motor delivers efficient operation. Little maintenance is required and the Emerson 48 Y-Frame Thru-Bolt motor is built to last
Advanced in its design, the Emerson 48 Y-Frame Thru-Bolt motor comes with a Y-Frame, indicating a special non-standard mounting configuration
The Emerson 48 Y-Frame Thru-Bolt motor is designed with standard efficiency, promising durability and quality performance while operating at an efficient level just below a premium model
| Pool Type: | Above Ground |
| Horsepower: | 2-1/2 HP |
| Service Factor: | 1.00 - 1.25 |
| Speed Settings: | Single Speed |
| Flange Type: | Thru Bolt Mount |
| Voltage: | 230V |
| Rating Type: | Up-Rated |
| Motor Frame: | 48 Frame |
| Energy Efficiency: | Standard |
| Product Type: | Pool Motor |
| Manufacturer: | U.S. Motors Emerson |
| Product Type: | Pool Part |
See Owner's Manual for details
